ProQual Level 3 Diploma for Electrical and Mechanical Draughtsman

The ProQual Level 3 Diploma for Electrical and Mechanical Draughtsman is a specialised qualification designed for professionals seeking to develop advanced technical skills in electrical and mechanical drafting. This course equips learners with the knowledge and practical expertise to create accurate engineering drawings, interpret technical specifications, and support design processes across various engineering and construction projects.

Learners will gain in-depth understanding of drafting principles, CAD (Computer-Aided Design) software, electrical schematics, mechanical components, and engineering standards. The course also covers techniques for producing detailed layouts, assembly diagrams, and technical documentation that comply with industry regulations and project requirements.

Ideal for aspiring electrical and mechanical draughtsmen, junior engineers, CAD technicians, and design professionals, this Level 3 Diploma enhances career prospects by providing recognised certification in engineering drawing and design. Completing this qualification demonstrates competence in producing precise technical drawings, supporting project planning, and facilitating communication between engineers, contractors, and project managers.

With a strong focus on practical application, industry standards, and software proficiency, the ProQual Level 3 Diploma for Electrical and Mechanical Draughtsman prepares learners for professional roles in engineering, manufacturing, construction, and design sectors. It also lays the foundation for further progression to higher-level diplomas and specialised engineering qualifications.

Overview

Certifying Body

ProQual

Course Duration

4-6 Months

Evaluation

Assignments Based

Study Units

7-Units

Learning Mood

Online

Qualification Structure

To achieve the ProQual Level 3 Diploma for Electrical and Mechanical Draughtsman ;

Candidates must complete the following 7 Mandatory units,

Mandatory Units

  • Project Planning and Health and Safety
  • Drawing Office Operations and Equipment
  • Site Observation and Technical Drawing
  • Fundamentals of Technical Drawing Application
  • Computer-Aided Design
  • Parametric Modelling for Workflows
  • Electrical and Mechanical Draughting and Technical Communication

Upon successful completion of the ProQual Level 3 Diploma for Electrical and Mechanical Draughtsman, learners will be able to:

Project Planning and Health and Safety (H&S)

  • Interpret project requirements and develop a technical plan.
  • Understand the relevant Health and Safety legislation and standards for a technical environment.
  • Conduct a risk assessment and implement safe working practices.
  • Communicate plans, Risks, hazards, and solutions to relevant personnel.

Drawing Office Operations and Equipment

  • Select, inspect, and safely use draughting tools, equipment, and materials for technical tasks.
  • Select and use measuring tools to gather accurate data in both drawings and site settings.
  • Produce and communicate technical drawings and documentation.
  • Use digital systems to create, present, and manage technical documents and data.
  • Handle data securely and maintain compliant records using digital and physical systems.

Site Observation and Technical Drawing

  • Understand drawing types, techniques, and applications.
  • Gather and document site-based information.
  • Use collated data to support effective technical drawing.

 Fundamentals of Technical Drawing Application

  • Understand technical drawings and associated documentation.
  • Apply draughting standards and conventions to technical drawings.
  • Construct 2D and pictorial representations of 3D objects using projections and geometry.
  • Produce accurate freehand and scaled manual drawings.

Computer-Aided Design

  • Set up and manage CAD systems and environment.
  • Create and annotate 2D CAD drawings with precision.
  • Use advanced CAD tools to organise and enhance drawings.
  • Create and export 3D CAD models.
  • Prepare final drawings using plotting and workflow integration

Parametric Modelling for Workflows

  • Set up and use a parametric workstation effectively.
  • Develop and document parametric components and assemblies.
  • Manage the use of parametric modelling outputs in digital product development.

Electrical and Mechanical Draughting and Technical Communication

  • Understand electrical and mechanical draughting requirements.
  • Understand the production of electrical and mechanical drawings from data and specifications.
  • Produce mechanical system drawings to specification.
  • Produce electrical system drawings to specification.
  • Coordinate and present multi-service drawings.
  • Review and revise drawing outputs to meet project needs.
Proqual approved Centre 768x526 1

Inspire Institute of Technologies is Approved Satellite Centre of ProQual

Entry Requirements

Entry Requirements

  • Learners must be at least 18 years old at the time of registration.
  • Candidates should hold a Level 2 qualification in engineering, electrical, mechanical, or a related discipline, or have equivalent academic or professional experience
  • Applicants are expected to have practical experience or exposure in engineering, drafting, CAD work, or related technical roles.
  • Learners must have a good command of written and spoken English to understand course materials, complete assessments, and produce professional technical drawings and reports.

What You Need to Know

The ProQual Level 3 Diploma for Electrical and Mechanical Draughtsman is ideal for aspiring electrical and mechanical draughtsmen, CAD technicians, junior engineers, and professionals seeking to develop expertise in creating accurate technical drawings for engineering and construction projects.

This course equips learners with advanced skills in electrical and mechanical drafting, CAD software, and technical drawing interpretation. Completing this qualification enhances your professional credibility, improves technical accuracy, and prepares you for key roles in engineering design and project planning.

  • Recognised Level 3 certification in electrical and mechanical drafting
  • Proficiency in CAD software and engineering drawing standards
  • Ability to produce precise technical drawings and layouts
  • Improved employability in engineering, manufacturing, and construction

Graduates can pursue roles such as Electrical Draughtsman, Mechanical Draughtsman, CAD Technician, Junior Design Engineer, Engineering Technician, or Project Design Support in manufacturing, construction, and engineering sectors.

Learners may progress to Level 4 or Level 5 diplomas in engineering, design, or CAD, or move into supervisory, design engineer, or specialist technical roles in mechanical and electrical engineering projects.

Yes, ProQual qualifications are internationally recognised, making this diploma valuable for professionals seeking engineering and drafting career opportunities both in the UK and overseas.
